표준 사양서 (JAC-35 ~ 270)

모델명				JAC-35	JAC-50	JAC-60	JAC-70	JAC-100	JAC-130	JAC-170	JAC-200	JAC-240	JAC-270
송풍기	급기(AIRFOIL)	풍량	CMH	3,500	5,000	6,000	7,000	10,000	13,000	17,000	20,000	24,000	27,000
			CMM	58	83	100	117	167	217	283	333	400	450
		정압	mmAq	75	75	75	75	85	85	85	85	85	85
		규격	DS	#2.5	#2.5	#2.5	#3.0	#3.0	#3.5	#3.5	#4.0	#4.0	#4.5
		모터	KW	1.5	2.2	3.75	3.75	5.5	7.5	7.5	11	11	15
	환기(SIROCCO)	풍량	CMH	2,800	4,000	4,800	5,600	8,000	10,400	13,600	16,000	19,200	21,600
			CMM	47	67	80	93	133	173	227	267	320	360
		정압	mmAq	45	45	45	45	50	50	50	50	50	50
		규격	DS	#2.0	#2.0	#2.0	#2.5	#2.5	#3.0	#3.0	#3.5	#3.5	#4.0
		모터	KW	0.75	1.5	2.2	2.2	3.75	3.75	5.5	5.5	7.5	11
코일	열량	냉수	kcal/h	26,000	35,000	43,000	61,000	26,000	35,000	43,000	61,000	43,000	61,000
		온수	kcal/h	30,000	39,000	47,000	63,000	30,000	39,000	47,000	63,000	47,000	63,000
		증기	kcal/h	47,000	60,000	76,000	102,000	47,000	60,000	76,000	102,000	76,000	102,000
필터	PRE	24" x 24"	EA	1	1	1	2	1	1	1	2	1	2
		24" x 12"	EA	0	1	2	1	0	1	2	1	2	1
	MED	24" x 24"	EA	1	1	1	2	1	1	1	2	1	2
		24" x 12"	EA	0	1	2	1	0	1	2	1	2	1
접속광경	냉온수입출구		A	40 x 2	40 x 2	50 x 2	50 x 2	65 x 2	65 x 2	80 x 2	80 x 2	80 x 2	80 x 2
	증기입구		A	32	40	50	50	32	40	50	50	50	50
	증기출구		A	20	32	32	32	20	32	32	32	32	32
	드레인		A	25	25	25	25	25	25	25	25	25	25
합산동력			KW	2.3	3.7	6.0	6.0	9.3	11.3	13	16.5	18.5	26

표준 사양서 (JAC-300 ~ 850)

모델명				JAC-300	JAC-350	JAC-420	JAC-480	JAC-540	JAC-600	JAC-660	JAC-720	JAC-780	JAC-850
송풍기	급기(AIRFOIL)	풍량	CMH	3,500	5,000	6,000	7,000	10,000	13,000	17,000	20,000	24,000	27,000
			CMM	58	83	100	117	167	217	283	333	400	450
		정압	mmAq	75	75	75	75	85	85	85	85	85	85
		규격	DS	#2.5	#2.5	#2.5	#3.0	#3.0	#3.5	#3.5	#4.0	#4.0	#4.5
		모터	KW	1.5	2.2	3.75	3.75	5.5	7.5	7.5	11	11	15
	환기(SIROCCO)	풍량	CMH	2,800	4,000	4,800	5,600	8,000	10,400	13,600	16,000	19,200	21,600
			CMM	47	67	80	93	133	173	227	267	320	360
		정압	mmAq	45	45	45	45	50	50	50	50	50	50
		규격	DS	#2.0	#2.0	#2.0	#2.5	#2.5	#3.0	#3.0	#3.5	#3.5	#4.0
		모터	KW	0.75	1.5	2.2	2.2	3.75	3.75	5.5	5.5	7.5	11
코일	열량	냉수	kcal/h	26,000	35,000	43,000	61,000	26,000	35,000	43,000	61,000	43,000	61,000
		온수	kcal/h	30,000	39,000	47,000	63,000	30,000	39,000	47,000	63,000	47,000	63,000
		증기	kcal/h	47,000	60,000	76,000	102,000	47,000	60,000	76,000	102,000	76,000	102,000
필터	PRE	24" x 24"	EA	1	1	1	2	1	1	1	2	1	2
		24" x 12"	EA	0	1	2	1	0	1	2	1	2	1
	MED	24" x 24"	EA	1	1	1	2	1	1	1	2	1	2
		24" x 12"	EA	0	1	2	1	0	1	2	1	2	1
접속광경	냉온수입출구		A	40 x 2	40 x 2	50 x 2	50 x 2	65 x 2	65 x 2	80 x 2	80 x 2	80 x 2	80 x 2
	증기입구		A	32	40	50	50	32	40	50	50	50	50
	증기출구		A	20	32	32	32	20	32	32	32	32	32
	드레인		A	25	25	25	25	25	25	25	25	25	25
합산동력			KW	2.3	3.7	6.0	6.0	9.3	11.3	13	16.5	18.5	26
